shux

why this exists

tmux ends at the byte stream.
shux owns the whole pipeline.

tmux is great. It's also from before agents existed. Its job ends where the terminal emulator's job begins — and a human at a keyboard is always assumed. shux assumes nothing of the sort.

tmux

·Plain-text control commands over a UDS socket.
·Output is bytes; the emulator paints them.
·Snapshots require a human-attached emulator + a screen capture tool.
·State mutations are sequential and best-effort.
·No structured event log; output is fire-and-forget.

— vs —

▸Length-prefixed JSON-RPC over UDS + TCP. Every shux subcommand is a thin RPC call.
▸Owns the byte-to-pixel pipeline. Returns PNG bytes via pane.snapshot.
▸Answers modern xterm-256color probes so rich TUIs start fast and render correctly.
▸Headless visual regression with no GUI, no display server, no emulator SDK.
▸Atomic state.apply batches. Optimistic concurrency on every entity.
▸Sealed, sequenced event bus with a separate data plane for PTY chunks.

human-first where it counts

Copying text should feel like a terminal, not a ceremony.

shux keeps the tmux-style copy mode for scrollback and search, but the everyday path is direct: drag visible text, release, paste. Right-click the selection when you want an explicit action.

Drag text

Select pane output without entering a modal copy screen.

Release to copy

OSC 52 writes the selected text to the clipboard.

Right-click

Use the inline Copy / Clear menu when you want confirmation.

●shux session attach review

$ cargo test --workspace
running 835 tests across 15 binaries
test copy_mode::mouse_selection selects text and copies on release ... ok
test attach::idle_repaint_volume ... ok
$ paste
selects text and copies on release
Copy OSC52
Clear Esc

agent-first, by construction

Everything an agent needs to drive a TUI is one RPC call away.

Spawn a session. Resize. Send keystrokes. Get a PNG back. Tear down. The same primitives a human uses are the same primitives an agent uses — no SDK, no screen-reading, no AppleScript bridge.

# 1 — declarative session spec (TOML).
# Same spec a human shux state apply's — same one an agent ships.

[session]
name = "review"

[[windows]]
title = "git"
[[windows.panes]]
command = ["lazygit"]

$ shux state apply review.toml
# → session created atomically. Pluck the first pane id:
$ PID=$(shux --format json session list \
        | jq -r '.sessions[0].pane_id')

$ shux pane set-size  -s review --cols 200 --rows 60
# → synchronous resize (VT + PTY).

$ shux pane send-keys -s review --text 'j'
# → navigate down one row.

$ shux --format json pane snapshot -s review \
    | jq -r .png_base64 \
    | base64 -d > out.png
# → 1800×1140 PNG of the current pane. No iTerm2 needed.

# Or drop to raw RPC for any registered method — no shell-escaping bait.
$ shux rpc call pane.send_keys --params @keys.json
$ echo '{"pane_id":"'$PID'","text":"j"}' | shux rpc call pane.send_keys --params -

The full surface

The RPC surface covers session/window/pane lifecycle, synchronous resize, scripted input, sampled PTY watching, lossless PTY recording, and pixel snapshots. Each maps 1:1 to a CLI subcommand.

session.*create / list / rename / kill / ensure
window.*create / list / focus / kill / ensure
pane.send_keystext or base64 control bytes
pane.set_sizesynchronous, ack via oneshot
pane.snapshotPNG, off-lock, budget-checked
pane.output.watchsampled sealed data-plane stream
pane.record.*lossless raw PTY transcript
state.applyatomic batch of typed Ops
events.historysequenced, gap-detectable

All methods accept JSON in, return JSON out, on stdin/stdout.

replaces these

If you'd reach for one of these, reach for shux.

shux collapses orchestration, scripted input, output capture, and pixel screenshots into one RPC surface. Same primitive, no extra tools.

If you'd reach for	For this job	The shux call
`tmux` · `screen` · `byobu`	Multiplex sessions / windows / panes	`shux state apply spec.toml` · `shux session attach`
iTerm2 (Python SDK / AppleScript)	Drive a terminal app from outside	`pane.send_keys` + `pane.snapshot`
`expect` · `pexpect` · `sexpect`	Scripted CLI / REPL interaction	`pane.send_keys` → `pane.wait_for` → `pane.capture`
iTerm2 `wait_for_text` / `wait_for_absent`	Block until screen contains (or stops containing) a needle	`pane.wait_for` — text · regex · `--absent`
`asciinema rec` · `script(1)`	Record a terminal session	`shux pane record --to FILE` lossless PTY bytes
`vhs` · `agg` · `terminalizer`	Generate TUI demo GIFs / WebPs	`window.snapshot` loop → `ffmpeg`
`termshot` · `freezeframe`	Still PNG of a terminal frame	`pane.snapshot` or `window.snapshot`
iTerm2 broadcast input	Send keystrokes to many panes at once	`pane.send_keys` fan-out across pane IDs
`ttyrec` · `termsh`	Replay a recorded session	Feed captured bytes back into a pane — workflow
GNU parallel `--tmux` mode	Run N tasks in N panes, watch in one place	`shux apply` a multi-pane template — workflow
Custom Bubbletea / ratatui test harness	Visual regression for your TUI	`window.snapshot` + golden-image diff

side by side

tmux is great. shux is different.

Both spawn PTYs and arrange them on screen. The contract beneath that is the part that diverges.

tmux v3.x · 18 years

Ubiquitous. Pre-installed on most servers.
Huge plugin ecosystem (tpm, oh-my-tmux, dozens of statuslines).
Mature key-binding model your fingers already know.
Battle-tested under decades of weird PTY behaviour.
Plain-text control protocol over a UDS socket.

If you're a human at a keyboard and tmux works, keep using tmux.

shux v0.8 · Rust

Length-prefixed JSON-RPC over UDS + TCP. Every CLI verb is a typed call.
Declarative workspace templates that apply atomically.
Optimistic concurrency on every entity — stale writes get rejected with a typed conflict error.
Sealed event bus, sequenced, gap-detectable. Separate data plane for PTY chunks.
Built-in rasterizer — one RPC returns PNG bytes of any live pane.
xterm-256color compatibility for DA/DSR, DECRQM, XTGETTCAP, OSC palette queries, and synchronized output.
Synchronous resize: the next snapshot sees the new dims, guaranteed.

If you're shipping agents, building TUIs, or want headless visual regression, this is for you.

in the wild

Nine tabs. Real `pane.snapshot` outputs, no mockups.

No mockups. No "rendered in After Effects". Pick a tab to see what shux's rasterizer produces when an agent drives a real TUI.

One shux window with three real agent CLIs running side-by-side as split panes: Claude Code on the left with the prompt 'Refactor this Rust Fibonacci impl for clarity' typed into its input box; OpenAI Codex in the middle with 'Find the memory leak in this Node.js worker' queued; opencode on the right with 'Audit this Python for thread-safety risks' staged. Each pane has its own title overlay (claude · refactor / codex · find leak / opencode · audit) and shux's three-zone status bar runs across the bottom (session name · window indicator · clock). One composed window.snapshot, no stitching. — **Three agent CLIs, one shux window.** One `state.apply` spawns claude · codex · opencode into three vertical splits; `pane.send_keys` types each prompt; `pane.set_title` pins the per-pane label. The whole frame — borders, title overlays, status bar — comes back as a single `window.snapshot`. No terminal emulator, no screen scraping, no stitching.

Three-section terminal scrollback inside one shux pane: BEFORE shows shux window list -s hr-target with one window 'demo·1' (renamed by the hello plugin); EDIT shows a sed -i swap of demo· to hot· in examples/plugins/hello/plugin.sh and a 'daemon log: watcher fired → plugin respawned' note; AFTER creates a new window which the just-respawned plugin renames to 'hot·1'. shux's three-zone status bar at the bottom shows the snapshot session 'hr-shoot · hot-reload'. — **Edit a plugin, save, see new code in <500ms.** `shux plugin install` watches the source by default. A `sed` swap of `demo·` → `hot·` in the running plugin triggers FSEvents (`~250ms` debounce) → plugin respawn. The very next `window.create` goes through the new code, tagged `hot·1`. Same daemon, same session, no reconnect.

7-frame animated replay of an agent driving lazygit: opening view → commits log → diff of one commit → branches → remotes → help overlay → back to files. Pointed at a freshly-cloned charmbracelet/bubbletea repo. — **An agent driving lazygit, scripted over JSON-RPC.** Navigate the commit log, open a diff with `Enter`, `?` for help, number keys to cycle panels. Each input is a `pane.send_keys`; each of the 7 frames is a real `pane.snapshot`. Asciinema with pixels instead of escape sequences.

4-pane shux workspace running bat, cargo nextest, shux --help, and a clock+git-log loop. 5 frames cycle through: initial spawn → settled → arrow-down sent to editor → tests pane resized → editor and tests swapped — **One `state.apply` spawns a 4-pane workspace.** `bat` · `cargo nextest` · `shux --help` · clock+git-log loop. Then 5 frames: arrow-down via `pane.send_keys`, resize via `pane.set_size`, swap quadrants via `pane.swap`. Same verbs as `tmux send-keys` / `resize-pane` / `swap-pane` — typed, sync, JSON-shaped.

shux attached to a 2-pane session named 'demo' showing lazygit (left) and bat rendering bubbletea's README (right), with focus-highlighted borders and shux's own three-zone status bar at the bottom — **shux running shux.** A `pane.snapshot` of one client running `shux session attach` against a 2-pane session. Borders, the `demo · 11/11 · ?` status bar, per-pane title overlays — all `RenderCompositor` output. Mouse-click moves focus, `Alt+hjkl` navigates, `Ctrl+Space` is the prefix. This PNG was produced without a terminal emulator.

bat rendering shux-raster's lib.rs test module — Rust syntax highlighting with line numbers and a soft TwoDark palette — **`bat crates/shux-raster/src/lib.rs`** in a shux pane. Every TwoDark colour survives the round-trip through `shux-vt`'s SGR parser and `shux-raster`'s glyph emitter — no re-render, no theme remap.

shux --help — paste-able agent reference. Every CLI verb maps to its RPC method, a 3-call workflow, and a replaces-these-tools table. Same rasterizer that snapshotted everything above.

A Python 3.13 REPL session with PyREPL syntax highlighting, showing an agent progressively driving the REPL through computations: importing math/statistics, computing roots, fitting a tiny dataset, defining a primes lambda, and inspecting the result list — **An agent driving Python's REPL.** `pane.send_keys` types each statement, `pane.wait_for` blocks on the response, `pane.capture` pulls the result back. Replaces `expect` / `pexpect` / iTerm2 `wait_for_text`. PyREPL 3.13 highlighting is free.

shux-raster attribute showcase: bold, dim, inverse, underline, strikethrough; 256-color palette ramp; truecolor RGB blocks; bottom-left cursor as an inverse cell — **shux-raster's hello banner.** Bold · dim · inverse · underline · strikethrough. ANSI 16, 256-cube, truecolor RGB. Cursor as an inverse cell. JetBrains Mono Regular bundled and rasterized in pure Rust via `fontdue`. No terminal emulator in the loop.

three calls from zero

Quickstart

Install the binary. Spawn a session. Snapshot it. That's the loop.

01

Install

One pre-built binary per platform. No daemons to register, no plugins to vendor. The daemon auto-starts on first use.

# macOS / Linux, arm64 or amd64
curl -sSf https://shux.pages.dev/install.sh | sh

02

Spawn a session

One verb creates an atomic session + initial window + pane, with the command of your choice running in it.

shux --format json session create demo -d -- htop \
  | jq -r .pane_id  # save PID for next step

03

Snapshot

One verb returns a base64-encoded PNG of the live pane. Decode and pipe it anywhere — a CI golden, a vision LLM, a webhook.

shux --format json pane snapshot -s demo \
  | jq -r .png_base64 \
  | base64 -d > frame.png

example frame.png produced by pane.snapshot — shux-raster's attribute showcase — `frame.png` — what came back. Real output, no mockup.

for agents

A Claude skill, ready to drop in.

One command installs the shux skill globally. The model then knows when to reach for shux instead of tmux, which RPC to call, and where the references live for deep dives.

$ npx skills add indrasvat/shux --global --yes

Browse the skill All the docs

# shux skill — top-of-file (≤30 lines)

name: shux
description: Drive terminal multiplexer sessions from an
  agent — multiplex, send keystrokes, snapshot pixel-perfect
  PNGs of any pane. Replaces tmux / screen / iTerm2 /
  expect/asciinema for agent-driven workflows.

Layout: shux init scaffolds .shux/
  (templates/, scripts/, goldens/, gitignored out/).

Quickstart: three verbs cover 80% of cases —
  1. shux state apply .shux/templates/spec.toml
  2. shux pane send-keys -s NAME --text '...'
  3. shux pane snapshot -s NAME -o .shux/out/frame.png

extend, don't fork

Agent-authored plugins. Any language. ~30 lines.

A plugin is any executable that speaks shux's line-delimited JSON-RPC dialect on stdin/stdout. It subscribes to bus events, calls the same RPC methods you use from outside (window.rename, pane.send_keys, state.apply), publishes its own events via event.publish (namespaced plugin.<id>.<type>), and persists state across hot reload via plugin.state.get/set. Bash, python, node, anything.

# Install, list, kill — the whole CLI surface for v0.
$ shux plugin install ./my-plugin.sh
# → spawned, handshook (5s budget), registered under manifest name

$ shux plugin list
# name · version · pid · subscribes · status · uptime

$ shux plugin kill hello
# → plugin.shutdown sent, 2s graceful window, SIGKILL fallback

The protocol, in six lines

handshakeone line in, one manifest line out (≤5 s)
events inone JSON line per matching bus event on stdin
rpc outwrite any registered method to stdout, response comes back on stdin
events outevent.publish emits plugin.<id>.<type> events for other plugins
stateplugin.state.get/set — survives hot reload, 256 KiB cap, per-plugin
shutdownplugin.shutdown frame, 2 s grace, then SIGKILL

trust model v0.19 ships a default-deny permission model on every plugin RPC frame: per-method sensitivity tiers, ownership-based auto-grant for entities the plugin created, shux plugin grant <name> <method> for the rest, NDJSON audit log per plugin. Identity is a per-install UUID — reinstalling with the same name does NOT inherit the predecessor's grants. Sandboxing of the plugin's own filesystem / network access (the WASM milestone) is still queued for later.

The 30-line example Protocol reference

shux: tmux for the agentic age.

tmux ends at the byte stream.shux owns the whole pipeline.
